The 450 filter vibrating screen is a compact, low-noise portable small vibrating separator. It performs excellently for powder materials with adundant coarse particles and liquid slurry filtration. When filtering paint with specific gravity 1.1 through a 325-mesh screen, its capacity reaches 1200 liters per hour; it processes 700 kg of flour hourly with a 30-mesh screen. It also delivers reliable filtration for ceramic glaze.

This single-deck separator fits manufacturers with low output or low-impurity materials. It serves food, pharmaceutical, chemical, metallurgy, abrasive, ceramic, coating, diamond and mining industries. The screen mesh stays unclogged without powder flying, and it can sieve materials down to 400 mesh.

Working Principle:

This screen takes vertical vibration motor as vibration source. Eccentric weights are installed on the top and bottom of the motor to generate three-dimensional compound vibration in horizontal, vertical and inclined directions. After materials flow onto the screen surface, 3D vibration spreads materials outward. Liquid and fine particles pass through mesh for discharge, while solid impurities stay on the screen and flow out from residue outlet. High-frequency vibration avoids mesh blockage. Operators can adjust amplitude and frequency to match different material properties.

Key Features:

1. Three-dimensional vibration boosts screening efficiency and fits diverse materials including powder and viscous slurry.

2. Mesh hardly clogs as continuous vibration automatically cleans screen cloth.

3. Compact footprint saves floor space, easy to move and install on site.

4. Simple mesh replacement; screen can be regenerated by back flushing to cut downtime.

Application Fileds:

1. Food processing: Fine filtration of soybean milk, starch slurry to remove impurities and guarantee finished product purity.

2. Chemical & pharmaceutical industry: Separate solid particles from liquid medicine and viscous chemicals to upgrade raw material quality.

3. Latex production: Remove impurities over 450 microns in latex purification to enhance product transparency and mechanical strength.

4. Ceramic industry: Filter ceramic slurry to elimicate incompletely ground particles and improve forming quality of ceramic blanks.



Inquiry Guide:

If you need small-sized single-deck filtration equipment for small-batch production, our low-noise 450 filter vibrating screen can meet your demands for powder and liquid separation. We cab adjust vibration parameters according to your materials and production capacity. Feel free to contact us to get professional technical solutions and free quotation.
